4.Advanced User Guidebook
running, the number of Pass/Fail will increase from the former number, not
from zero.
5. When the waveform playback mode is on, Pass/Fail is used to test the
played-back waveform specially.
Use Executive Buttons
Executive Buttons include Copy, Default, Run/Stop, Single, Autoset.
Copy
You can save the waveform by just pushing the Copy panel button in any user
interface. The source wave and the storage location are according to the
settings of the Save function menu when the Type is Wave. For more details,
please see "Save Function Menu" on P56.
Default
Shortcut keys to restore factory settings.
Run/Stop
Enable or disable sampling on input signals.
Notice: When there is no sampling at STOP state, the vertical division and the
horizontal time base of the waveform still can be adjusted within a certain
range, in other words, the signal can be expanded in the horizontal or vertical
direction.
When the horizontal time base is ≤50ms, the horizontal time base can be
expanded for 4 divisions downwards.
Single
Push this button you can set the trigger mode as single directly, so when
trigger occurs, acquire one waveform then stop.
Autoset
It's a very useful and quick way to apply a set of pre-set functions to the
incoming signal, and display the best possible viewing waveform of the signal.
The details of functions applied to the signal when using Autoset are shown
as the following table:
Adjust to the proper division.
Adjust to the proper position.
Adjust to the proper division
