Panasonic Lumix DMC-LX100 Operating Instructions

18
SQW0038
Before Use
Names and Functions of Main Parts
[MENU/SET] button / Cursor button / Control dial
[MENU/SET] button
Use this button to display the menus, enter the settings, etc. (→31)
Cursor button
This button is used to move the cursor on the menu screens and for
other functions. (→32)
You can perform the following operations while recording.
[ISO] button ( ) (→136)
[WB] (White Balance) button ( ) (→103)
[ ] (Drive Mode) button ( )
Single (→141), Burst (→142), Auto Bracket (→145),
Aspect Bracket (→147), Self-timer (→148), Panorama (→150)
[ ] (AF Mode) button ( ) (→115, 131)
Control dial
Turn the dial to select setting items and change setting values.
(→32, 67)
Disabling the button and dial operation (while recording)
When the [Cursor Button Lock] is assigned to the function button, operation of the
[MENU/SET] button, cursor button, and control dial is disabled. (→38)
Enabling/disabling the operation guide display
→ [Custom] → [Dial Guide] → [ON] / [OFF]
• When you set the operation guide to [ON], the operation
guide for the control ring ([
]), control dial ([ ]), and other
parts appear on the recording screen.
●
In this manual, the button that is to be used is indicated by .

Panasonic Lumix DMC-LX100 Specifications

General

Megapixel	12.8 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4112 x 3088 pixels
Still image resolution(s)	[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom	4 x
Optical zoom	3.1 x
Focal length range	10.9 - 34 mm
Maximum aperture number	16
Minimum aperture number	1.7
Lens structure (elements/groups)	11/8
Maximum focal length (35mm film equiv)	75 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 8.5 m
Flash range (wide)	0.6 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	921000 pixels
Magnification	1.39 x
Viewfinder screen size	0.38 \
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Image processor	Venus
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF, Exif 2.3, RAW
Image quality adjustment	Colour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	350 shots
Product color	Silver
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader

Weight and Dimensions

Depth	55 mm
Width	114.8 mm
Height	66.2 mm
Weight	351 g
Weight (including battery)	393 g
