291
SQW0038
Others
Optional accessories
External Flash (optional)
When you use the flashes (optional: DMW-FL220, DMW-FL360L, or DMW-FL580L), a
wider effective flash range is provided than with the flash (supplied).
Preparation
Set the camera [ON/OFF] switch to [OFF].
Removing the hot shoe cover
The hot shoe cover is already attached to the hot shoe at the time of purchase.
Remove the hot shoe cover by pulling it in the
direction indicated by arrow while pressing
it in the direction indicated by arrow
Be sure to attach the hot shoe cover when the hot shoe
is not in use.
Keep the hot shoe cover safely after removing it so that
you do not lose it.
Using the flash (DMW-FL360L: optional)
Attach the external flash to the hot shoe and then turn on the camera and the external
flash
Set the menu
[Rec] → [Flash]
Press to select [Flash Mode] and press [MENU/SET]
Press to select the item and press [MENU/SET]
While the external flash is connected, the following icons are displayed.
: External flash Forced ON
:
External flash Red-Eye Removal Forced ON
*
: External flash Slow Sync.
:
External flash Red-Eye Removal Slow Sync.
*
:
External flash Forced OFF
Signal-flashing with wireless flashes is also disabled.
*
When the flash mode is set to [AUTO] or [MANUAL] on the external flash, you cannot select
the item.

Table of Contents

Other manuals for Panasonic Lumix DMC-LX100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-LX100 and is the answer not in the manual?

Panasonic Lumix DMC-LX100 Specifications

General IconGeneral
Megapixel12.8 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size4/3 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4112 x 3088 pixels
Still image resolution(s)[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom4 x
Optical zoom3.1 x
Focal length range10.9 - 34 mm
Maximum aperture number16
Minimum aperture number1.7
Lens structure (elements/groups)11/8
Maximum focal length (35mm film equiv)75 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)0.3 - 8.5 m
Flash range (wide)0.6 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)921000 pixels
Magnification1.39 x
Viewfinder screen size0.38 \
USB version-
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editingCrop, Resizing, Rotating
Photo effectsArt, Black&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Image processorVenus
Self-timer delay2, 10 s
Camera file systemDCF, DPOF, Exif 2.3, RAW
Image quality adjustmentColour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Power source typeBattery
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)350 shots
Product colorSilver
Cables includedAC, USB
Bundled softwarePHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth55 mm
Width114.8 mm
Height66.2 mm
Weight351 g
Weight (including battery)393 g
