309
SQW0038
Others
Menu list
[Playback]
You can specify picture protection, resizing, print settings, and other settings for pictures
you have taken.
[Slide Show] Automatically play pictures in order. →204
[Playback Mode]
You can narrow down the pictures to be displayed with set filters,
such as categories or favourite pictures.
→206
[Location Logging]
You can write location information (longitude/latitude) sent from the
smartphone to the pictures.
→207
[RAW Processing]
You can use the camera to develop still pictures that were
recorded in RAW format. The created still pictures are saved in
JPEG format.
→208
[Title Edit] Allows characters (comments) to be entered on a recorded picture. →211
[Text Stamp]
You can stamp the recording date and time, names, travel
destination, travel dates, etc. on the recorded still pictures.
→212
[Video Divide] A single motion picture can be split into 2 parts. →214
[Time Lapse Video]
You can create a motion picture from the pictures in a group that
was recorded using [Time Lapse Shot].
→215
[Stop Motion Video]
You can create a motion picture from the pictures in a group that
was recorded using [Stop Motion Animation].
→215
[Resize] Picture size can be reduced. →216
[Cropping] Enlarge your still pictures and crop unwanted areas. →217
[Rotate] Manually rotate pictures by 90°. →218
[Rotate Disp.] Automatically rotate portrait pictures. →218
[Favorite]
Allows a label to be assigned to a picture with a mark to set it as
your favourite picture.
→219
[Print Set] Sets the pictures and the number of pictures to be printed. →220
[Protect] Set protection to prevent deletion of pictures by mistake. →221
[Face Rec Edit]
Edit or delete the recognition information for pictures with mistaken
Face Recognition.
→222
[Picture Sort]
You can set the display sequence used for playing back pictures
on this unit.
→223
[Delete Confirmation]
You can set the Yes/No options that you want to select first on the
confirmation screen when you delete a picture from either [Yes]
or [No].
→223

Table of Contents

Other manuals for Panasonic Lumix DMC-LX100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-LX100 and is the answer not in the manual?

Panasonic Lumix DMC-LX100 Specifications

General IconGeneral
Megapixel12.8 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size4/3 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4112 x 3088 pixels
Still image resolution(s)[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom4 x
Optical zoom3.1 x
Focal length range10.9 - 34 mm
Maximum aperture number16
Minimum aperture number1.7
Lens structure (elements/groups)11/8
Maximum focal length (35mm film equiv)75 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)0.3 - 8.5 m
Flash range (wide)0.6 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)921000 pixels
Magnification1.39 x
Viewfinder screen size0.38 \
USB version-
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editingCrop, Resizing, Rotating
Photo effectsArt, Black&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Image processorVenus
Self-timer delay2, 10 s
Camera file systemDCF, DPOF, Exif 2.3, RAW
Image quality adjustmentColour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Power source typeBattery
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)350 shots
Product colorSilver
Cables includedAC, USB
Bundled softwarePHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth55 mm
Width114.8 mm
Height66.2 mm
Weight351 g
Weight (including battery)393 g
