Panasonic Lumix DMC-LX100 Operating Instructions

276
SQW0038
Connecting with other devices
Viewing on TV screen
You can view pictures on a TV screen by connecting your camera to your TV with the
HDMI micro cable or AV cable (optional).
Preparation
Turn off both camera and TV.
1
Connect camera to TV
Check the plug direction and insert it straight in. (If the cable is inserted in the wrong
direction, the plug could become deformed and cause faulty operation) Also, do not
insert into the wrong socket. Doing so may cause damage to this unit.
■
To connect with an HDMI micro cable
An HDMI micro cable can be used to enable viewing of still and motion pictures in
high-resolution.
Align the marks, and insert.
[HDMI] socket
To HDMI video/audio
input socket
HDMI micro cable
Use a “High Speed HDMI micro cable” with the HDMI logo. Cables that do not
comply with the HDMI standards will not work.
“High Speed HDMI micro cable” (Type D-Type A plug, up to 2 m (6.6 feet) long)
■
To connect with an AV cable (optional)
Align the marks, and insert.
[AV OUT/DIGITAL] socket
AV cable (optional)
Yellow:
To video socket
White:
To audio socket
*
*
Monaural audio output.
2
Turn on the TV and switch the TV input source to match the
connection socket
3
Turn on the camera and press the playback button

Panasonic Lumix DMC-LX100 Specifications

General

Megapixel	12.8 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4112 x 3088 pixels
Still image resolution(s)	[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom	4 x
Optical zoom	3.1 x
Focal length range	10.9 - 34 mm
Maximum aperture number	16
Minimum aperture number	1.7
Lens structure (elements/groups)	11/8
Maximum focal length (35mm film equiv)	75 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 8.5 m
Flash range (wide)	0.6 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	921000 pixels
Magnification	1.39 x
Viewfinder screen size	0.38 \
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Image processor	Venus
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF, Exif 2.3, RAW
Image quality adjustment	Colour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	350 shots
Product color	Silver
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader

Weight and Dimensions

Depth	55 mm
Width	114.8 mm
Height	66.2 mm
Weight	351 g
Weight (including battery)	393 g
