Panasonic SDR-S50 User Manual

112
VQT2L35
Others
Specifications
SD Video Camera
SD/HDD Video Camera
Information for your safety
Power source: DC 5.0 V (When using AC adaptor)
DC 3.6 V (When using battery)
Power consumption: Recording:
2.9 W
3.5 W
Charging:
7.7 W
7.7 W
Signal system CCIR: 625 lines, 50 fields PAL colour signal
Recording
format
SD card Normal recording mode: Based on the SD-Video standard
HDD Normal recording mode:
Independent standard
Long recording mode: Independent standard
Image sensor 1/8z CCD image sensor
To ta l: 80 0 K
Effective pixels:520 K (4:3), 470 K (16:9)
Lens Auto Iris, F1.9 to F5.7
Focal length:
1.48 mm to 104 mm
Macro (Wide range AF)
35 mm equivalent:
Optical zoom:
37.4 mm to 2625 mm (4:3)
36.5 mm to 2571 mm (16:9)
Enhanced optical zoom:
33.5 mm to 2625 mm (4:3)
32.8 mm to 2571 mm (16:9)
Minimum focus distance:
Approx. 2 cm (Wide)/Approx. 1.5 m (Tele)
SDR-S50
SDR-H85
SDR-S50
SDR-H85
SDR-S50
SDR-H85
SDR-H85
SDRS50&H85GN-VQT2L35_mst.book 112 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
