Panasonic SDR-S50 User Manual

20
VQT2L35
Caution:
Check that the access lamp has gone off.
1 Open the LCD monitor.
2 Open the SD card cover and insert (remove) the SD card into (from)
the card slot.
≥ Face the label side B in the direction shown in the illustration and press it straight in as far
as it will go.
≥ Press the centre of the SD card and then pull it straight out.
3 Securely close the SD card cover.
≥ Do not touch the terminals on the back of the SD card.
≥ See page 110 for details on handling the SD card.
Inserting/removing an SD card
When using an SD card not from Panasonic, or one previously used on other equipment,
for the first time on this unit, format the SD card. (l 74) When the SD card is formatted, all
of the recorded data is deleted. Once the data is deleted, it cannot be restored.
Access lamp [ACCESS] A
≥ When this unit is accessing the SD card, the access lamp lights up.


SDRS50&H85GN-VQT2L35_mst.book 20 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
