Panasonic SDR-S50 User Manual

64
VQT2L35
Playback of the first scene starts after
playback of the last scene finishes.
Select the menu. (l 23)
The indication appears on the full
screen views.
≥ All the scenes are played back repeatedly.
(When playing back motion pictures by
date, all the scenes on the selected date
are played back repeatedly.)
If playback of a scene was stopped halfway,
the playback can be resumed from where it
was stopped.
Select the menu. (l 23)
If playback of a motion picture is stopped,
appears on the thumbnail view of the
stopped scene.
≥ The memorised resume position is cleared
if you turn off the power or change the
mode.
(The setting of [RESUME PLAY] does not
change.)
Repeat playback
[VIDEO SETUP] # [REPEAT PLAY] #
[ON]
Resuming the previous
playback
[VIDEO SETUP] # [RESUME PLAY] #
[ON]
SDRS50&H85GN-VQT2L35_mst.book 64 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
