Panasonic SDR-S50 User Manual

65
VQT2L35
Playback
Playback
2
Still picture playback
1 Change the mode to .
2 Use the joystick to select the
play mode select icon
A , then
press the centre of the joystick.
3 Select the media you wish to
play back, then press the
centre of the joystick.
Select [PICTURE/SD CARD] to play back
the SD card.
Select [PICTURE/HDD] to play back the HDD.
Select [PICTURE/SD CARD] to play back
the SD card.
4 Select the still picture to be
played back, then press the
joystick.
≥ The operation icon will be displayed or hidden
each time the centre of the joystick is pressed.
≥ Next (previous) page can be displayed by
selecting / .
SDR-S50
SDR-H85
SDRS50&H85GN-VQT2L35_mst.book 65 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
