Panasonic SDR-S50 User Manual

81
VQT2L35
≥ Only discs that have been copied by connecting this unit to the DVD burner or
created with VideoCam Suite 3.0 can be played back.
A Mini AB USB Connection Cable (supplied with DVD burner)
1 Connect this unit to the DVD burner to prepare for playback. (l 77)
≥ When playing back on a TV, connect this unit to the TV. (l 75)
2 Use the joystick to select a scene or a still picture, then press the
centre of the joystick for playback.
≥ The playback operation is performed the same as when playing back motion pictures or
still pictures. (l 59, 65)
≥ It will return to step 5 on page 78 when [Return] is selected in the thumbnail screen.
≥ It is also possible to switch the media to play back by selecting the Play Mode Select icon.
It is possible to select [VIDEO/DISC] or [PICTURE/DISC] when the DVD burner is
connected.
Playing back the copied disc
SDRS50&H85GN-VQT2L35_mst.book 81 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
