Panasonic SDR-S50 User Manual

63
VQT2L35
3 (Only when [MINUTES] has been
selected under step 2)
Set the time and then press the
centre of the joystick.
4 Choose the thumbnail from
which you wish to begin
playback, then press the
centre of the joystick.
≥ Next (previous) thumbnail can be
displayed by selecting / .
Scenes recorded on the same day can be
played back in succession.
1 Select the date select icon and
press the joystick.
A Date select icon
2 Select the playback date, then
press the joystick.
The scenes recorded on the date selected
are displayed as thumbnails.
3 Select the scene to be played
back, then press the joystick.
≥ Playing back of all the scenes returns if
the power is turned off or the mode is
switched.
≥ Even if scenes are recorded on the same
day, they are grouped separately in the
following cases.
jWhen the number of scenes exceeds 99
jWhen the world time setting is changed
Playing back motion
pictures by date
SDRS50&H85GN-VQT2L35_mst.book 63 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
