23
VQT2L35
Preparation
Setup
5
Using the menu screen
1 Press the MENU button.
2 Select the desired top menu A,
then move the joystick right or
press the joystick.
3 Select the submenu item B,
then move the joystick right or
press the joystick.
≥ Descriptions of submenus and current
settings on menus are displayed scrolling
at the bottom of the screen.
4 Select the desired setting, then
press the joystick to enter the
selection.
To get back to the previous screen
Move the joystick left.
To exit the menu screen
Press the MENU button.
MENU
ENTER
SDRS50&H85GN-VQT2L35_mst.book 23 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
