Panasonic SDR-S50 User Manual

58
VQT2L35
If auto focusing is difficult due to the conditions, then use manual focus.
¬ Change the mode to .
≥ Press the iA/MANUAL button to switch to manual mode (l 55)
1 (When MF assist function is used)
Select the menu. (l 23)
2 Use the joystick to select [MF]
3 Bring the subject into focus
with the joystick.
The area in focus will be displayed in blue.
Display will return to normal approximately
2 seconds after the completion of the focus
adjustment operation.
≥ When [MF ASSIST] is set to [OFF], the
blue area is not displayed.
≥ To return to Auto focus, either switch to
[AF] as in step 2, or repress the iA/
MANUAL button.
≥ The blue display does not appear in the
motion picture that is actually recorded.
Recording with manual focus
[RECORD SETUP] # [MF ASSIST] #
[ON]
5/5
5/5
NEXT
NEXT
5/5 NEXT
MNL
SDRS50&H85GN-VQT2L35_mst.book 58 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
