Panasonic SDR-S50 User Manual

8
VQT2L35
Accessories
Check the accessories before using this unit.
Product numbers correct as of December 2009. These may be subject to change.
Some optional accessories may not be
available in some countries.
Battery pack
VW-VBL090
(SDR-S50)
Battery pack
VW-VBK180
(SDR-H85)
AC adaptor
VSK0712
AC cable
K2CJ29A00002
AV cable
K2KYYYY00054
USB cable
K1HY04YY0032
CD-ROM
Software
Optional accessories
Battery charger (VW-BC10GN)
Battery pack (lithium/VW-VBL090)
(SDR-S50)
Battery pack (lithium/VW-VBK180)
Battery pack (lithium/VW-VBK360)
Video DC light (VW-LDC103E)
*
Light bulb for video DC light (VZ-LL10E)
Shoe adaptor (VW-SK12E)
DVD burner (VW-BN2)
Accessory kit (VW-ACK180GN)
* The shoe adaptor VW-SK12E (optional)
is necessary.
SDRS50&H85GN-VQT2L35_mst.book 8 ページ ２００９年１２月２９日 火曜日 午前１０時３０分

Panasonic SDR-S50 Specifications

General

Digital zoom	3500 x
Optical zoom	78 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	36.5 - 2571 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Effective megapixels (movie)	0.52 MP
Interface	USB 2.0
Video out	1
Auto focus	No
Power requirements	AC/DC, 3.6 - 5.0 V
Power consumption (typical)	7.7 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Still image resolution(s)	640 x 360, 640 x 480
Audio formats supported	AAC, MP1
Camera shutter speed	1/30 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Product color	Silver, White
Bundled software	VideoCam Suite V3.0

Weight and Dimensions

Depth	107.3 mm
Width	54.9 mm
Height	64 mm
Weight	212 g
