10
Paper width deflector
of auto feed tray
Slide paper width deflector to adapt to paper width.
11
Paper length deflector
of auto feed tray
Slide paper length deflector to adapt to paper length.
12
Clip of extended tray
of auto feed tray
For adjustment of length extension of the tray .
Rear View
1
For connecting product to computer with USB cable.
2
Network Interface
For connecting product to network with network cable.
3
For connecting product to power with power cord.
4
For paper release when it gets jammed.
5
Duplex Printing Unit
For paper feed at duplex printing and paper release when paper
gets jammed at
duplex printing.
Note： · Printer appearance may differ because of various models and functions,
so the schematic diagram is only for your reference.
Rear Cover
Power Interface
USB Interface
To Next Page
