Start-up manual
COMPAX-M / -S
26
7.4 COMPAX 35XXS unit features
The 35 kW servo control COMPAX 35XXM - a performance upgrade to the
COMPAX family.
!
Compact unit with output currents of 50
Aeff
/ 100
Aeff
(<5s) with integrated power
unit.
!
Additional COMPAX-M controllers of up to 15 KW can be arranged in rows.
7.4.1 Plug and connection assignment COMPAX 35XXM
Digital
COMPAX-M
X5 X7
IN OUT
X19
Control
H1
X6
Input
Output
Status
Value
+-
Enter
Ready
Error
RS 232
Test
Control
X8 X10
X9 X11
Number
X13
Encoder
X9 Test
X6 RS232
X7 OUT
X5 IN
Bus
systems:
X19
Control
X8/X10 In-/
Output
X11 Control
X14/X15
HEDA
X17 Initiators
X16 Absolute
encoder
X12
Resolver
Before wiring up, always de-energize the unit.
Even once the mains supply has been switched off, dangerous
levels of voltage can remain in the system for up to 5 min.
When working with motors without a holding brake, the brake lines
must not be connected to COMPAX
Caution!
If the unit has no control voltage, no displays will indicate that operating
voltage is present.
