ELECTRICITY
53
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
ELECTRICITY
Ignition principle schematic
1. Ignition switch
2. Battery
3. CDI unit
4. Spark plug socket
5. Spark plug
6. HT coil
7. Starter resistor
8. Automatic starter
9. Magneto flywheel
10.Voltage regulator
11.Carburetor heater
12.Carburettor heater thermo-switch
13.Drive sensor
7,5A
OFF
ON
R
-
U
P
PER LE
VEL
LOWE
RL
E
VE
L
XX
.XX
XX
X.
X
XX
X
JN-BE
JN-NR
VE-NR
JN-BE
VE
RG
RG
NR
VE
VE
VE
JN
JN
JN-BA
RG-NR
RG-NR
VE
BA-NR
BA-NR
BE
NR
VE
JN
JN
VE
1
2
3
6
4
5
7
8
9
10
13
12
11
