Controls
7 - 4
1
2
3
0
7.08 Feed regulator (on machines with subclass -911/97)
● Turn knurled screw 1 to adjust the stitch
length for sewing forwards.
● Turn knurled screw 2 to adjust the stitch
length for sewing backwards.
Reverse stitches can be set as
long as required, independently
of forward stitches.
Fig. 7 - 08
Fig. 7 - 07
2
1
1
7.07 Feed regulator/reverse sewing
● The stitch length is adjusted by turning
the knurled nut on lever 1.
● To reverse the sewing direction press
lever 1 fully upwards.
