1 105 Speed for start backtack B, C 300 - 2000 600
110 Speed for end backtack B, C 300 - 2000 800
6 607 Speed max. B, C 300 - 6000 ▲
609 Cutting speed 1 B, C 60 - 300 180
7 700 Needle position 0 B, C 0 - 255 *
(needle reference position)
702 Needle position 1 (needle lowered) B, C 0 - 255 80
703 Needle position 2 (take-up lever raised) B, C 0 - 255 225
705 Needle position 5 (end cutting signal 1) B, C 0 - 255 100
706 Needle position 5 (start cutting signal 2) B, C 0 - 255 80
707 Needle position 9 (start thread tension B, C 0 - 255 195
release/start thread catcher)
722 Acceleration ramp B,C 1 - 60 45
723 Brake ramp B,C 1 - 60 40
734 Tact output A2 (thread trimming) B,C 001 - 009 0
760 Multiplier for the fixed value (200) for A, B, C 0 - 250 5
stitch count
799 Selected machine class C 1 - 4 2
10.08.01 Parameter list
10.08 Parameter settings
(only on machines with Quick-EcoDrive and control unit P40ED)
● The selection of the user level and the alteration of parameters is described in the separa-
te instruction manual for the drive unit.
▲
See Chapter 3 Specifications
*
Adjustment see Chapter 8.05 Basic position of the machine drive unit .
Group
