Controls
7 - 5
Fig. 7 - 09
7.
09
Adjusting nut for the top feed stroke
Switch the machine off!
Danger due to unintentional
starting of the machine!
●
Loosen screw
1
at the back of the
machine.
●
Open cover
2
.
●
Loosen screw
3
and adjust lever
accordingly.
●
Close cover
2
and tighten screw
1
.
2
3
-
+
1
7
.10
Control panel
(only on machines with Quick-Eco drive)
The description can be found in the separate instruction manual for the control panel.
