Dismantling and mounting
Power supply
FOR SAFTEY REASONS ALWAYS DISCONNECT THE MAIN POWER CORD FROM THE MACHINE
BEFORE REMOVING THE POWER SUPPLY.
Dismantling
1. When removing the Power Supply; please remove all the covers fi rst.
2. Remove the Main PC board.
3. Disconnect the cable.
4. Remove the four screws that holds the Power supply in position.
5. Remove the power supply.
Mounting
In Reverse order.
