PIAGGIO beverly 500 User Manual

CAUTION
USED OILS CONTAIN SUBSTANCES HARMFUL TO THE ENVIRONMENT. FOR
OIL REPLACEMENT, CONTACT AN AUTHORISED SERVICE CENTRE, WHICH
IS EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY FRIEND-
LY AND LEGAL WAY.
Recommended products
AGIP CITY HI TEC 4T
Engine oil
SAE 5W-40, API SL, ACEA A3, JASO MA Synthetic oil
Characteristic
Engine oil (at oil and filter change)
1.5 lt.
03_05
Hub oil level (03_05)
Check the oil in the rear hub.
To check the rear hub oil level, proceed as follows:
1.Park the scooter on level ground and rest it on its centre stand.
2. Unscrew the oil dipstick «A», dry it with a clean cloth. Reinsert it and screw it tightly
into place.
3. Pull out the dipstick and check that the oil level is between the MIN and MAX ref-
erence marks. If the oil level is below the MIN notch, top up with the required amount
of hub oil.
4. Screw the dipstick back in, checking that it is locked in place.
36
3 Maintenance

PIAGGIO beverly 500 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	493 cc
Fuel System	Electronic fuel injection
Front Tire	110/70 - 16
Length	2, 150 mm
Width	780 mm
Seat Height	790 mm
Maximum Torque	43 Nm @ 5, 500 rpm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	240 mm disc
ABS	No
Rear Suspension	Dual hydraulic shock absorbers
