PIAGGIO beverly 500 User Manual

Recommended products
AGIP FILTER OIL
Oil for air filter sponge
Mineral oil with specific additives for increased adhesiveness
03_09
03_10
Air filter cleaning (03_09, 03_10)
Periodically check the exhaust blow-by and condensate pipe in area "E" and empty it
into a suitable container.
Position the scooter on the centre stand and remove cover "F", without removing any
other components, working from underneath the scooter and noting that it is located
behind the shoulder of the transmission air intake.
Collect the old oil in a suitable container and do not dispose of it in the environment.
Carry out the operation on the cold engine in order to avoid burns caused by coming
into contact with the engine.
CAUTION
USED OILS CONTAIN SUBSTANCES HARMFUL TO THE ENVIRONMENT. FOR
OIL REPLACEMENT, CONTACT AN AUTHORISED SERVICE CENTRE, WHICH
IS EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY FRIEND-
LY AND LEGAL WAY.
42
3 Maintenance

PIAGGIO beverly 500 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	493 cc
Fuel System	Electronic fuel injection
Front Tire	110/70 - 16
Length	2, 150 mm
Width	780 mm
Seat Height	790 mm
Maximum Torque	43 Nm @ 5, 500 rpm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	240 mm disc
ABS	No
Rear Suspension	Dual hydraulic shock absorbers
