- Repeat the check at 3 - 4 points.
- Place the tightener cursor in the rest position,
keeping the retain tab pressed.
- Install a new tightener on the cylinder using a new
gasket.
- Tighten the two fastening screws to the prescri-
bed torque.
Locking torques (N*m)
Tightener fastening screws: 11 ÷ 13
- Insert the spring with the central screw and the
washer.
- Tighten the central screw to the prescribed tor-
que.
Locking torques (N*m)
Tightener screw: 5 to 6
Engine Beverly 500 i.e.
ENG - 134
