FUEL GAUGE DAMPER
Specification Desc./Quantity
1 Fuel reserve warning light
2 Fuel level gauge output
3 Float input
4 Test (not connected)
5 Ground lead
6 + permanent power supply
Electrical system Beverly 500 i.e.
ELE SYS - 50
