- Insert the special tool as shown in the figure.
- Insert the retaining band of the two half-rings.
- Using a 19 mm hexagonal spanner, extract the
roller bearing.
Specific tooling
020458Y Puller for lower bearing on steering
tube
Refitting
Reassembly of tapered bearing in steering
tube
- Insert the a new plate and a new dust guard in
the steering tube
- Insert the a new tapered bearing in the steering
tube
- Using the special tool and a mallet to move the
dust guard and the bearing in abutment.
Specific tooling
006029Y Punch for fitting fifth wheel seat on
steering tube
X8 400 Euro 3 Suspensions
SUSP - 301
