22
> Antes de empezar > Nombres de las piezas > Instalación > Initial Setup > Reproducción
Configuración avanzada | Actualización de Firmware | Otros
E
S
Spotify
Wi-Fi
PioneerHMXXxxxxxx
b
a
c
d
1
4
3
2
Operaciones básicas
Podrá reproducir Spotify Connect si conecta la unidad a la
misma red que un smartphone o tableta. Para activar
Spotify Connect, debe instalar la aplicación de Spotify y en
su teléfono inteligente o tableta y crear una cuenta de
Spotify Premium.
1. Conecte el smartphone a la misma red que la unidad.
2. Haga clic en el icono de conexión de la pantalla de
reproducción de pista de la aplicación Spotify.
3. Seleccione esta unidad.
0 Esta unidad se muestra como "Pioneer HM76D (76 o
86D) XXXXXX".
4. La unidad se encenderá automáticamente, el selector de
entrada cambiará a NETWORK y se iniciará la
transmisión de Spotify.
0 Si "Option Setting" - "Power Off Setting" - "Network
Standby" está configurado como "Off" en el menú
Setup, encienda la unidad manualmente y pulse
NETWORK en el mando a distancia.
0 Consulte el siguiente enlace para configurar Spotify:
www.spotify.com/connect/
0 El software de Spotify está sujeto a licencias de terceros.
Puede consultarlas aquí:
www.spotify.com/connect/third-party-licenses
También se pueden llevar a cabo estas operaciones del
mando a distancia.
(a) Si se pulsa durante la reproducción, este botón la
pausa. Si se pulsa con la reproducción en pausa, esta
se reanuda.
(b) Este botón reproduce la pista anterior.
(c) Este botón reproduce la pista siguiente.
(d) Iniciar la reproducción repetida o aleatoria. Al pulsar
este botón repetidamente se alterna entre los modos de
repetición y reproducción aleatoria.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pioneer X-HM76 and is the answer not in the manual?

Pioneer X-HM76 Specifications

General IconGeneral
TypeHome audio micro system
Cassette deckNo
Product colorBlack
Disc loading typeTray
Optical disc playerYes
Number of optical discs1 discs
Volume controlDigital
Impedance4 Ω
Speaker type2-way
Frequency range70 - 40000 Hz
RMS rated power100 W
Woofer diameter120 mm
Tweeter diameter25 mm
Number of speakers2
Signal-to-Noise Ratio (SNR)83 dB
Total Harmonic Distortion (THD)10 %
Bluetooth version4.1
Phono inputs (RCA)1
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Frequency band2.4 GHz
Wi-Fi standards802.11a, 802.11b, 802.11g
Display diagonal3.5 \
Bluetooth profilesA2DP, AVCTP, HID, HOGP
Ethernet LAN data rates10, 100 Mbit/s
Apple docking compatibilityNot supported
Power sourceAC
Input voltage220-230 V
Input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)40 W
Display typeLCD
AM band range530 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Preset stations quantity40
Internet radio services supportedTuneIn
Disc types supportedCD, CD-R, CD-RW
Playback disc formatsCD audio
Audio formats supportedAAC, AIFF, DSD, FLAC, MP3, WAV, WMA
Weight and Dimensions IconWeight and Dimensions
Package typeBox
Main unit weight3500 g
Rear speaker depth217 mm
Rear speaker height263 mm
Rear speaker weight3400 g
Main unit dimensions (WxDxH)290 x 333 x 98 mm
