Page #38 background imageLoading...
Page #38 background image
> Before Start > Part Names > Install > Initial Setup > Playback
Advanced Setup | Firmware Update | Others
37
E
N
Select the language displayed on the display.
English (Default Value), German, French, Spanish, Italian, Dutch, Swedish, Russian,
Chinese
Tuner Setting
X-HM76D, X-HM86D, XC-HM86D
Bluetooth Setting
System Info
The MAC address of this unit and the current firmware version will be displayed.
Tuning Mode Set the tuning method for the radio.
"Auto" (Default Value): Radio stations that can be received are
tuned automatically.
"Manual": Tune to stations manually. If the "Tuning Mode" is set to
“Manual”, the reception for FM broadcasts will be monaural rather
than stereo, irrespective of the sensitivity of the reception.
FM Search Level
¢
You can choose to have only those FM stations with strong
reception selected when tuning into stations automatically if
tuning regularly stops on FM stations with weak reception.
"Normal" (Default Value)
"Strong": Select only stations with strong reception.
DAB Scan
¢
You can run the auto scan when new DAB stations are added or
when you move house.
DAB DRC
¢
With the DRC (Dynamic Range Control) setting, you can reduce
the dynamic range of DAB digital radio so that you can still hear
quiet parts even when listening at low volume levels - ideal for
listening to the radio late at night when you don't want to disturb
anyone.
"0" (Default Value): DRC off
"1": Large reduction in dynamic range
"1/2": Small reduction in dynamic range
Preset Name You can give names to the stations that you have registered. For
details on how to enter text, refer to " Entering text" (ÄP34). After
finishing input, press ENTER.
Bluetooth Select whether or not to use the BLUETOOTH function.
"On" (Default Value): Enables connection with a BLUETOOTH
enabled device by using the BLUETOOTH function. Select "On"
also when making various BLUETOOTH settings.
"Off": When not using the BLUETOOTH function
Auto Input Change The input of the unit will automatically be switched to
"BLUETOOTH" when connection is made from a BLUETOOTH
enabled device to the unit.
"On" (Default Value): The input will automatically become
"BLUETOOTH" when a BLUETOOTH enabled device is
connected.
"Off": The function is disabled.
0 If the input is not switched automatically, set to "Off" and
change the input manually.
Auto Reconnect This function automatically reconnects to the BLUETOOTH
enabled device connected last when you change the input to
"BLUETOOTH".
"On" (Default Value): Use this function
"Off": Do not use this function
0 This may not work with some BLUETOOTH enabled devices.
Pairing Information You can initialize the pairing information saved on this unit.
Press y/z to select "Clear", then press ENTER to initialize the
pairing information stored in this unit.
0 This function does not initialize the pairing information on the
BLUETOOTH enabled device. When pairing the unit again
with the device, be sure to clear the pairing information on the
BLUETOOTH enabled device in advance. For information on
how to clear the pairing information, refer to the BLUETOOTH
enabled device's instruction manual.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pioneer X-HM76 and is the answer not in the manual?

Pioneer X-HM76 Specifications

General IconGeneral
TypeHome audio micro system
Cassette deckNo
Product colorBlack
Disc loading typeTray
Optical disc playerYes
Number of optical discs1 discs
Volume controlDigital
Impedance4 Ω
Speaker type2-way
Frequency range70 - 40000 Hz
RMS rated power100 W
Woofer diameter120 mm
Tweeter diameter25 mm
Number of speakers2
Signal-to-Noise Ratio (SNR)83 dB
Total Harmonic Distortion (THD)10 %
Bluetooth version4.1
Phono inputs (RCA)1
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Frequency band2.4 GHz
Wi-Fi standards802.11a, 802.11b, 802.11g
Display diagonal3.5 \
Bluetooth profilesA2DP, AVCTP, HID, HOGP
Ethernet LAN data rates10, 100 Mbit/s
Apple docking compatibilityNot supported
Power sourceAC
Input voltage220-230 V
Input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)40 W
Display typeLCD
AM band range530 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Preset stations quantity40
Internet radio services supportedTuneIn
Disc types supportedCD, CD-R, CD-RW
Playback disc formatsCD audio
Audio formats supportedAAC, AIFF, DSD, FLAC, MP3, WAV, WMA
Weight and Dimensions IconWeight and Dimensions
Package typeBox
Main unit weight3500 g
Rear speaker depth217 mm
Rear speaker height263 mm
Rear speaker weight3400 g
Main unit dimensions (WxDxH)290 x 333 x 98 mm
