General Specifications
Analog Audio Output Section
RMS Output Power
0 X-HM76D, X-HM76 : 50 W + 50 W
0 X-HM86D, XC-HM86D : 65 W + 65 W
(4 ohms, 1 kHz THD 10%)
Tone Control Characteristics
0
w10 dB (100 Hz (BASS))
0
w10 dB (10 kHz (TREBLE))
Supported Speaker Impedance
0 4 ohms - 16 ohms
Tuner Section
X-HM76
Tuning Frequency Range (FM)
0 87.5 MHz - 108.0 MHz, RDS
Antenna (FM)
0 75 Ω unbalanced
Preset Channel
0 40
X-HM76D, X-HM86D, XC-HM86D
Tuning Frequency Range (FM)
0 87.5 MHz - 108.0 MHz, RDS
Tuning Frequency Range (DAB)
0 174.928 MHz - 239.200 MHz
Antenna (FM/DAB)
0 75 Ω unbalanced
Preset Channel
0 40
CD Section
Media/Format
0 CD : Standard CD
0 CD-R/RW : CD format/MP3, WMA File
Digital Audio Input
Front/Rear USB
0 Type A, USB2.0 High Speed
DC Output
0 5 V 1 A (Rear)/5 V 0.5 A (Front)
Optical Digital Input
0 Optical Jack
Network Section
Wired LAN
0 Ethernet Jack
0 10BASE-T/100BASE-TX
Wireless LAN (Wi-Fi)
0 IEEE 802.11 a/b/g/n standard
0 5 GHz/2.4 GHz band
Bluetooth Section
Communication system
0 BLUETOOTH Specification version 4.1
Frequency band
0 2.4 GHz (2.402 GHz - 2.480 GHz)
Modulation method
0 FHSS (Freq Hopping Spread Spectrum)
Compatible Bluetooth profiles
0 A2DP 1.2
0 AVRCP 1.3
0 HOGP-Host (Client)
0 HOGP-HID Device (Server)
0 HID Service (HIDS)
Supported Codecs
0 SBC
0 AAC
Transmission range (A2DP)
0 20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
＊
0 (Line of sight approx.) 10 m.
＊ The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a
microwave oven, static electricity, cordless phone,
reception sensitivity, antenna's performance, operating
system, software application, etc.
General
Power Supply
0 AC 220 - 230 V, 50/60 Hz
Power Consumption
0 X-HM76D, X-HM76 : 40 W
0 X-HM86D, XC-HM86D : 42 W
0 0.3 W (In Standby)
0 2.5 W (In Standby, Network Standby : On, Network
Setting : Wired)
0 2.8 W (In Standby, Network Standby : On, Network
Setting : Wi-Fi)
0 2.2 W (In Standby, Bluetooth Wakeup : On)
0 2.9 W (In Standby, Network Standby : On, Network
Setting : Wi-Fi, Bluetooth Wakeup : On)
Auto Standby
0 On (20 min)/Off

Pioneer X-HM76 Specifications

General

Type	Home audio micro system
Cassette deck	No
Product color	Black
Disc loading type	Tray
Optical disc player	Yes
Number of optical discs	1 discs
Volume control	Digital
Impedance	4 Ω
Speaker type	2-way
Frequency range	70 - 40000 Hz
RMS rated power	100 W
Woofer diameter	120 mm
Tweeter diameter	25 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	83 dB
Total Harmonic Distortion (THD)	10 %
Bluetooth version	4.1
Phono inputs (RCA)	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Frequency band	2.4 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g
Display diagonal	3.5 \
Bluetooth profiles	A2DP, AVCTP, HID, HOGP
Ethernet LAN data rates	10, 100 Mbit/s
Apple docking compatibility	Not supported
Power source	AC
Input voltage	220-230 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	40 W
Display type	LCD
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	TuneIn
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	CD audio
Audio formats supported	AAC, AIFF, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Package type	Box
Main unit weight	3500 g
Rear speaker depth	217 mm
Rear speaker height	263 mm
Rear speaker weight	3400 g
Main unit dimensions (WxDxH)	290 x 333 x 98 mm
