Pioneer X-HM76 User Manual

E
N
Before Start
What's in the box ..........................................................................2
Part Names
Front Panel ...................................................................................4
Rear Panel (X-HM76D, X-HM86D, XC-HM86D) ..........................5
Rear Panel (X-HM76) ...................................................................6
Remote Controller .........................................................................7
Display ..........................................................................................8
Speakers System (X-HM76D, X-HM76) .......................................9
Speakers System (X-HM86D) ....................................................10
Install
Connect the Speakers ................................................................ 11
Connecting the antennas and power cord, etc. ..........................12
Initial Setup
Power On & Initial Setup .............................................................13
Time settings ..............................................................................16
Playback
Playing CDs ................................................................................17
USB Storage Device/HDD ..........................................................19
Internet Radio .............................................................................21
Spotify .........................................................................................22
Listening to the FM Radio ...........................................................23
Listening to DAB Digital Radio (X-HM76D, X-HM86D, XC-HM86D) ......26
BLUETOOTH
®
............................................................................27
AirPlay
®
......................................................................................29
Playing audio from an external device ........................................30
Music Server ...............................................................................31
Using the alarm to start play .......................................................33
Entering text, adjusting sound quality, etc. .................................34
Advanced Setup
Advanced Settings.......................................................................35
Firmware Update
Firmware Update ........................................................................39
Others
Troubleshooting ..........................................................................41
General Specifications ................................................................44
License and Trademark Information ...........................................46
> Before Start > Part Names > Install > Initial Setup > Playback
Advanced Setup | Firmware Update | Others
NETWORK CD RECEIVER SYSTEM
X-HM76D
X-HM76
X-HM86D
NETWORK CD RECEIVER
XC-HM86D
Instruction
Manual

Pioneer X-HM76 Specifications

General

Type	Home audio micro system
Cassette deck	No
Product color	Black
Disc loading type	Tray
Optical disc player	Yes
Number of optical discs	1 discs
Volume control	Digital
Impedance	4 Ω
Speaker type	2-way
Frequency range	70 - 40000 Hz
RMS rated power	100 W
Woofer diameter	120 mm
Tweeter diameter	25 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	83 dB
Total Harmonic Distortion (THD)	10 %
Bluetooth version	4.1
Phono inputs (RCA)	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Frequency band	2.4 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g
Display diagonal	3.5 \
Bluetooth profiles	A2DP, AVCTP, HID, HOGP
Ethernet LAN data rates	10, 100 Mbit/s
Apple docking compatibility	Not supported
Power source	AC
Input voltage	220-230 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	40 W
Display type	LCD
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	TuneIn
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	CD audio
Audio formats supported	AAC, AIFF, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Package type	Box
Main unit weight	3500 g
Rear speaker depth	217 mm
Rear speaker height	263 mm
Rear speaker weight	3400 g
Main unit dimensions (WxDxH)	290 x 333 x 98 mm
