2.52
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
SUSPENSION SYSTEM
SPRING ADJUSTMENT (NON-FOX)
The front and rear shock absorber springs are adjustable
by rotating the adjustment cam to change ride height.
WARNING
Uneven adjustment may cause poor handling of the
vehicle, which could result in an accident and serious
injury or death. Always adjust both the left and right
springs equally.
1. Position the vehicle on a level surface and stop the
engine.
2. Raise and safely support front or rear of vehicle off
the ground to allow the suspension to fully extend.
NOTICE
The tires should not be touching the ground.
3. To adjust the suspension, rotate the adjustment cam
q
clockwise to increase spring tension or counter-
clockwise to decrease spring tension.
Shock Spanner Wrench:
2877408
4. Each notch of the adjustment will add 6% - 8% more
preload to the spring over the primary position.
MAINTENANCE
