9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
4. Remove the fasteners
r
retaining the stabilizer bar
link to the stabilizer bar.
FRONT STABILIZER BAR INSTALLATION
1. Install the fasteners
r
retaining the stabilizer bar link
to the stabilizer bar. Torque fasteners to specification.
TORQUE
Stabilizer Bar Link Fasteners:
40 ft-lb (54 Nm)
2. Install the stabilizer bar from the side.
3. Install the fasteners retaining the stabilizer bar mount
to the frame. Torque fasteners to specification.
TORQUE
Stabilizer Bar Mount Bracket Fasteners:
17 ft-lb (23 Nm)
4. Install the nut
q
retaining the front stabilizer bar link
w
to the upper control arm
e
on both sides. Torque
fasteners to specification.
TORQUE
Stabilizer Bar Link Fasteners:
40 ft-lb (54 Nm)
STEERING / SUSPENSION
