9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
3.89
VALVE COVER INSTALLATION
1. Apply anti-seize compound to spark plug threads.
2. Install spark plugs
q
and torque to specification.
3. Prepare valve cover sealing surfaces by cleaning
thoroughly to remove all residue.
4. Install valve cover seal
w
.
5. Install the four valve cover shoulder bolts
e
and new
isolators
r
using a T40 driver.
6. Torque valve cover bolts to specification.
TORQUE
Spark Plugs:
7 ft-lbs (10 Nm)
Valve Cover Bolts:
7 ft-lbs (10 Nm)
ENGINE / COOLING SYSTEM
