9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
8.29
2015-2016 Shock Valving RZR XP 1000
COMPRESSION REBOUND CLICKER
1.55 x 0.010 1.500 x 0.008 1.00 x 0.015
1.20 x 0.008 0.900 x 0.008 1.00 x 0.015
1.55 x 0.010 1.45 x 0.008 0.90 x 0.015
1.20 x 0.008 1.30 x 0.008 0.70 x 0.015
1.50 x 0.010 1.20 x 0.008 0.70 x 0.015
1.45 x 0.010 1.10 x 0.008
1.30 x 0.010 1.00 x 0.008
1.20 x 0.010 0.900 x 0.008
1.10 x 0.012
0.75 x 0.065
(top-out)
0.900 x 0.012
0.800 x 0.012
1.50 x 0.125
(top-out)
No Piston Bleed Orifice
2015-2016 Shock Valving RZR XP 1000 High
Lifter
COMPRESSION REBOUND CLICKER
1.85 x 0.010 1.50 x 0.010 1.00 x 0.015
1.75 x 0.010 1.45 x 0.010 1.00 x 0.015
1.65 x 0.010 1.30 x 0.010 0.90 x 0.015
1.55 x 0.008 1.20 x 0.010 0.600 x 0.015
1.00 x 0.010 1.10 x 0.010 0.600 x 0.015
1.55 x 0.008 1.00 x 0.010
1.55 x 0.008 0.90 x 0.010
1.55 x 0.008 0.80 x 0.010
1.55 x 0.008
1.55 x 0.008
1.45 x 0.010
1.00 x 0.095
(top-out)
1.30 x 0.012
1.20 x 0.012
1.50 x 0.125
(top-out)
Piston Bleed Orifice: 0.100″
2015 Shock Valving RZR XP 1000 Desert
Edition
COMPRESSION REBOUND CLICKER
1.55 x 0.010 1.50 x 0.008 1.00 x 0.015
1.20 x 0.008 0.900 x 0.008 1.00 x 0.015
1.55 x 0.010 1.45 x 0.008 0.900 x 0.015
1.20 x 0.008 1.30 x 0.008 0.700 x 0.015
1.55 x 0.008 1.20 x 0.008 0.700 x 0.015
1.50 x 0.010 1.10 x 0.008
1.45 x 0.010 1.00 x 0.008
1.30 x 0.010 0.900 x 0.008
1.20 x 0.010
0.750 x 0.065
(top-out)
1.10 x 0.012
0.900 x 0.012
0.800 x 0.012
1.50 x 0.125
(top-out)
No Piston Bleed Orifice
STEERING / SUSPENSION
