Integrator's Reference Manual for the VSX Series
3 - 84 www.polycom.com/videodocumentation
Peripherals Commands
Command Syntax Description Example
graphics-
monitor
graphicsmonitor
<tv|fxvga|visualcon-
cert|1|2|vcnx|get>
Where:
•tv: Selects the TV monitor as the
graphics monitor. The graphics and
video are displayed on the TV
monitor.
• fxvga: Selects the VSX system’s
VGA monitor as the graphics
monitor. Enable this option if you
have a high-resolution VGA monitor
or projector connected to the rear
panel of the system.
• vcnx: Selects Visual Concert VSX
as the graphics monitor. Enable this
option if Visual Concert VSX is
connected to your system and the
graphics monitor is directly
connected to Visual Concert VSX.
This allows your system to display
your computer desktop on your
system’s VGA monitor.
• get: Returns the current setting.
Sets or gets the graphics
monitor to one of three choices:
a TV monitor, a VGA monitor, or
a Visual Concert VSX monitor.
When you use this command to
set the graphics monitor, you
automatically turn off the other
two choices.
User interface screen location:
System > Admin Settings >
Monitors > Monitors: Graph-
ics Content Display
graphicsmonitor
fxvga
monitor1 monitor1<4:3|16:9|get>
Where:
• 4:3|16:9: Sets the display format
ratio to 4:3 (standard display) or 16:9
(wide-screen display).
•get: Returns the current setting.
Sets the display format for
monitor 1. User interface screen
location:
System > Admin Settings >
Monitors > Monitors: Monitor
1
monitor1 4:3
monitor2 monitor2 <off|4:3|get>
Where:
• off: The video signal is not sent out
to the second monitor outputs.
• 4:3: Sets the display format ratio to
4:3 (standard).
•get: Returns the current setting.
Sets the display format for
monitor 2.
User interface screen location:
System > Admin Settings >
Monitors > Monitors: Monitor
2
monitor2 4:3
sleep sleep Puts the VSX system in sleep
mode.
sleep
