Quectel EC200A Series User Manual

LTE Standard Module Series
2.5. EVB
In order to help customers to develop applications with the module conveniently, Quectel supplies an
evaluation board (EVB), USB data cable, earphone, antenna, and other peripherals to control or to test
the module. For more details, please refer to document [1].
USB_BOOT
115
DI
Forces the module to
enter download mode
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power
domain.
Active High.
It is
recommended
to reserve test
points.
WAKEUP_IN*
1
DI
Wake up the module
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power
domain.
If unused, keep
it open.
AP_READY
2
DI
Application processor
ready
1.8 V power
domain.
If unused, keep
it open.
W_DISABLE#
4
DI
Airplane mode control
1.8 V power
domain.
Pull-up by
default.
In low voltage
level, module
can enter into
airplane mode.
If unused, keep
it open.
RESERVED Pins
Pin Name
Pin No.
Comment
RESERVED
3,18, 37–40,43, 47, 55, 73–84,113, 114, 116–144
Keep these pins
unconnected.
