6.3. Power Consumption
Table 36: The Module Power Consumption
EC200A-CN
Description
Conditions
Typ.
Unit
OFF state
Power down
11
uA
Sleep state
AT+CFUN=0 (USB disconnected)
0.86
mA
EGSM900 @ DRX = 2 (USB disconnected)
1.71
mA
EGSM900 @ DRX = 5 (USB disconnected)
1.27
mA
EGSM900 @ DRX = 5 (USB suspend)
1.43
mA
EGSM900 @ DRX = 9 (USB disconnected)
1.14
mA
DCS1800 @ DRX = 2 (USB disconnected)
1.70
mA
DCS1800 @ DRX = 5 (USB disconnected)
1.26
mA
DCS1800 @ DRX = 5 (USB suspend)
1.41
mA
DCS1800 @ DRX = 9 (USB disconnected)
1.13
mA
WCDMA @ PF = 64 (USB disconnected)
2.37
mA
WCDMA @ PF = 64 (USB suspend)
2.53
mA
WCDMA @ PF = 128 (USB disconnected)
1.66
mA
WCDMA @ PF = 256 (USB disconnected)
1.31
mA
WCDMA @ PF = 512 (USB disconnected)
1.14
mA
LTE-FDD @ PF = 32 (USB disconnected)
2.04
mA
LTE-FDD @ PF = 64 (USB disconnected)
1.46
mA
LTE-FDD @ PF = 64 (USB suspend)
1.60
mA
LTE-FDD @ PF = 128 (USB disconnected)
1.19
mA
