Quectel EC200A Series User Manual

LTE Standard Module Series
5.1.2. Tx Power
The following table shows the RF output power of the module.
Table 29: Tx Power
.
5.1.3. Rx Sensitivity
The following table shows conducted Rx sensitivity of the module.
Frequency
Max. Tx Power
Comments
GSM850
33 dBm ± 2 dB
5 dBm ± 5 dB
EGSM900
33 dBm ± 2 dB
5 dBm ± 5 dB
DCS1800
30 dBm ± 2 dB
0 dBm ± 5 dB
PCS1900
30 dBm ± 2 dB
0 dBm ± 5 dB
GSM850(8-PSK)
27 dBm ± 3 dB
5 dBm ±5 dB
GSM900 (8-PSK)
27 dBm ± 3 dB
5 dBm ± 5 dB
DCS1800 (8-PSK)
26 dBm ± 3 dB
0 dBm ± 5 dB
PCS1900(8-PSK)
26 dBm ± 3 dB
0 dBm ± 5 dB
WCDMA B1/B2/B4/B5/B8
24 dBm +1/-3 dB
< -49 dBm
LTE-FDD
B1/B2/B3/B4/B5/B7/B8/B20/B28/B66
23 dBm ± 2 dB
< -39 dBm
LTE-TDD B34/B38/B39/B40/B41
23 dBm ± 2 dB
< -39 dBm
In GPRS 4 slots Tx mode, the maximum output power is reduced by 4 dB. The design conforms to the
GSM specification as described in Chapter 13.16 of 3GPP TS 51.010-1.
NOTE
