Quectel EC200A Series User Manual

LTE Standard Module Series
6 Electrical Characteristics and
Reliability
6.1. Absolute Maximum Ratings
Absolute maximum ratings for power supply and voltage on digital and analog pins of the module are
listed in the following table.
Table 34: Absolute Maximum Ratings
Parameter
Min.
Max.
Unit
VBAT_RF/VBAT_BB
-0.3
5.5
V
USB_VBUS
-0.3
5.5
V
Peak Current of VBAT_BB
-
0.8
A
Peak Current of VBAT_RF
-
1.8
A
Voltage on Digital Pins
-0.3
2.3
V
Voltage at ADC0
0
VBAT_BB
V
Voltage at ADC1
0
VBAT_BB
V
