Quectel EG06 Series User Manual

LTE-A Module Series
EG06 Hardware Design
EG06_Hardware_Design 22 / 89
Status Indication
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
STATUS
171
DO
Indicate the
module’s operation
status.
V
OH
min=1.35V
V
OL
max=0.45V
1.8V power domain.
If unused, keep it
open.
NET_MODE
147
DO
Indicate the
module’s network
registration mode
V
OH
min=1.35V
V
OL
max=0.45V
1.8V power domain.
If unused, keep it
open.
NET_
STATUS
170
DO
Indicate the
module’s network
activity status
V
OH
min=1.35V
V
OL
max=0.45V
1.8V power domain.
If unused, keep it
open.
USB Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
USB_VBUS
32
PI
USB connection
detection
Vmax=5.25V
Vmin=3.0V
Vnorm=5.0V
USB_DP
34
IO
USB 2.0 differential
data bus - plus
Compliant with USB
2.0 standard
specifications.
Require differential
impedance of 90Ω.
USB_DM
33
IO
USB 2.0 differential
data bus - minus
Compliant with USB
2.0 standard
specifications.
USB_ID
36
DI
OTG identification
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep it
open.
USB_SS_
TX_P
38
AO
USB 3.0 super
speed
transmission- plus
Compliant with USB
3.0 standard
specifications.
Require differential
impedance of 90Ω.
USB_SS_
TX_M
37
AO
USB 3.0 super
speed
transmission-
minus
USB_SS_
RX_P
40
AI
USB 3.0 super
speed receiving-
plus
Require differential
impedance of 90Ω.
USB_SS_
RX_M
41
AI
USB 3.0
super-speed
receiving- minus
