1. It is recommended to add an RC (R = 22 Ω, C = 22 pF) circuit on the PCM lines, especially for
PCM_CLK.
2. EM06 series module works as a master device pertaining to I2C interface.
3.10. Control and Indication Interface
The following table shows the pin definition of control and indication interfaces.
Table 12: Pin Definition of Control and Indication Interfaces
1)
means GNSS enablement control function is under development.
3.10.1. W_DISABLE1#
The module provides a W_DISABLE1# signal to disable or enable the airplane mode through hardware
method. The W_DISABLE1# pin is pulled up by default. When AT+CFUN=1, driving W_DISABLE1# to
low level will enable the airplane mode in which the RF function is disabled.
Pin Name
Pin No.
I/O
Power Domain
Description
WWAN_LED#
10
OD
3.3 V
An open collector and active low signal.
Indicates the RF status of the module.
WAKE_ON_WAN#
23
OD
1.8 V
An open collector and active low signal.
Wakes up the host.
W_DISABLE1#
8
DI
1.8/3.3 V
Airplane mode control. Active low.
W_DISABLE2#
1)
26
DI
1.8/3.3 V
GNSS enablement control. Active low.
DPR
25
DI
1.8 V
Dynamic power reduction. High level by
default.
NOTES
NOTE
