Quectel EM06 Series User Manual

LTE-A Module Series
EM06 Series Hardware Design
EM06_Series_Hardware_Design 59 / 69
6.6. RF Receiving Sensitivity
The following tables show conducted RF receiving sensitivity of EM06 series modules.
Table 35: EM06-E Conducted RF Receiving Sensitivity
Table 36: EM06-J Conducted RF Receiving Sensitivity
Frequency
Primary
(Typ.)
Diversity
(Typ.)
SIMO
1)
(Typ.)
SIMO
2)
(Worst Case)
WCDMA B1
-109.5 dBm
-109 dBm
-111 dBm
-106.7 dBm
WCDMA B3
-109 dBm
-109 dBm
-111 dBm
-103.7 dBm
WCDMA B5
-109 dBm
-109 dBm
-111 dBm
-104.7 dBm
WCDMA B8
-109 dBm
-109 dBm
-111 dBm
-103.7 dBm
LTE-FDD B1 (10 MHz)
-97.5 dBm
-97 dBm
-100 dBm
-96.3 dBm
LTE-FDD B3 (10 MHz)
-97 dBm
-97 dBm
-100 dBm
-93.3 dBm
LTE-FDD B5 (10 MHz)
-97 dBm
-99 dBm
-100.5 dBm
-94.3 dBm
LTE-FDD B7 (10 MHz)
-95.5 dBm
-98 dBm
-99.5 dBm
-94.3 dBm
LTE-FDD B8 (10 MHz)
-97.5 dBm
-98 dBm
-100.5 dBm
-93.3 dBm
LTE-FDD B20 (10 MHz)
-96.5 dBm
-98.5 dBm
-100.5 dBm
-93.3 dBm
LTE-FDD B28 (10 MHz)
-96.5 dBm
-98.5 dBm
-100.5 dBm
-94.8 dBm
LTE-TDD B38 (10 MHz)
-96 dBm
-97.5 dBm
-99 dBm
-96.3 dBm
LTE-TDD B40 (10 MHz)
-96 dBm
-97.5 dBm
-98.5 dBm
-96.3 dBm
LTE-TDD B41 (10 MHz)
-95.5 dBm
-97.5 dBm
-98.5 dBm
-94.3 dBm
Frequency
Primary
(Typ.)
Diversity
(Typ.)
SIMO
1)
(Typ.)
SIMO
2)
(Worst Case)
WCDMA B1
-109 dBm
-109 dBm
-111 dBm
-106.7 dBm
WCDMA B3
-109 dBm
-109 dBm
-111 dBm
-103.7 dBm
