Quectel EM06 Series User Manual

LTE-A Module Series
EM06 Series Hardware Design
EM06_Series_Hardware_Design 52 / 69
6.3. I/O Requirements
Table 30: I/O Requirements
1)
V
DD18
refers to I/O power domain.
6.4. Current Consumption
Table 31: EM06-E Current Consumption
Parameter
Description
Min.
Max.
Unit
V
IH
Input high voltage
0.7 × V
DD18
1)
V
DD18
+ 0.3
V
V
IL
Input low voltage
-0.3
0.3 × V
DD18
V
V
OH
Output high voltage
V
DD18
- 0.5
V
DD18
V
V
OL
Output low voltage
0
0.4
V
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
OFF state
Power down
50
μA
Sleep state
AT+CFUN=0 (USB disconnected)
2.77
mA
WCDMA PF = 64 (USB disconnected)
4.06
mA
WCDMA PF = 128 (USB disconnected)
3.66
mA
WCDMA PF = 256 (USB disconnected)
3.48
mA
LTE-FDD PF = 64 (USB disconnected)
4.49
mA
LTE-FDD PF = 128 (USB disconnected)
3.89
mA
LTE-FDD PF = 256 (USB disconnected)
3.59
mA
NOTE
