EM06 Series Hardware Design
EM06_Series_Hardware_Design 47 / 69
1.
1)
LTE-FDD B29 and B32 are supported only for Rx and secondary component carrier(s).
2. “*” means under development.
5.1.2.2. GNSS Operating Frequencies
The following table shows frequency specifications of the GNSS antenna connector.
Table 25: GNSS Frequencies
5.2. Antenna Installation
5.2.1. Antenna Requirements
The following table shows the requirements on Main antenna, Rx-diversity antenna and GNSS antenna.
Table 26: Antenna Requirements
Type
Requirements
GNSS
1)
Frequency range: 1559–1609 MHz
Polarization: RHCP or linear
VSWR: < 2 (Typ.)
LTE-FDD B30
2305–2315
2350–2360
MHz
LTE-FDD B66
1710–1780
2110–2200
MHz
LTE-TDD B41
2496–2690
2496–2690
MHz
Type
Frequency
Unit
GPS/Galileo/QZSS
1575.42 ±1.023
MHz
GLONASS
1597.5–1605.8
MHz
BeiDou/Compass
1561.098 ±2.046
MHz
NOTES
