6.5. RF Output Power
The following table shows the RF output power of EM06 series modules.
Table 34: RF Output Power
LTE-FDD B13 CH5230 @ 22.7 dBm
660
mA
LTE-FDD B25 CH8365 @ 23 dBm
705
mA
LTE-FDD B26 CH8865 @ 22.9 dBm
650
mA
LTE-FDD B30 CH9820 @ 23 dBm
700
mA
LTE-FDD B66 CH132322 @ 23 dBm
720
mA
LTE-TDD B41 CH40740 @ 23 dBm
390
mA
2CA data
transfer
LTE-FDD B2 + B2 @ 23.2 dBm
825
mA
LTE-FDD B4 + B4 @ 22.6 dBm
910
mA
LTE-FDD B7 + B7 @ 22 dBm
950
mA
LTE-FDD B25 + B25 @ 22.5 dBm
800
mA
LTE-FDD B66 + B66 @ 21.7 dBm
800
mA
LTE-TDD B41 + B41 @ 23.1 dBm
550
mA
WCDMA voice
call
WCDMA B2 CH9800 @ 23.1 dBm
540
mA
WCDMA B4 CH1638 @ 23.2 dBm
530
mA
WCDMA B5 CH4407 @ 22.9 dBm
610
mA
Frequency
Max.
Min.
WCDMA bands
24 dBm +1/-3 dB
< -50 dBm
LTE-FDD bands
23 dBm ±2 dB
< -40 dBm
LTE-TDD bands
23 dBm ±2 dB
< -40 dBm
