Quectel EM06 Series User Manual

LTE-A Module Series
EM06 Series Hardware Design
EM06_Series_Hardware_Design 57 / 69
Table 33: EM06-A Current Consumption
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
OFF state
Power down
50
μA
Sleep state
AT+CFUN=0 (USB disconnected)
2.96
mA
WCDMA PF = 64 (USB disconnected)
3.76
mA
WCDMA PF = 128 (USB disconnected)
3.29
mA
WCDMA PF = 512 (USB disconnected)
3.14
mA
LTE-FDD PF = 32 (USB disconnected)
5.12
mA
Idle state
WCDMA PF = 64 (USB disconnected)
21.3
mA
WCDMA PF = 64 (USB connected)
28.2
mA
LTE-FDD PF = 64 (USB disconnected)
21.9
mA
LTE-FDD PF = 64 (USB connected)
28.5
mA
LTE-TDD PF = 64 (USB disconnected)
21.6
mA
LTE-TDD PF = 64 (USB connected)
28.49
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B2 HSDPA CH9800 @ 23 dBm
520
mA
WCDMA B2 HSUPA CH9800 @ 23 dBm
520
mA
WCDMA B4 HSDPA CH1638 @ 22.9 dBm
500
mA
WCDMA B4 HSUPA CH1638 @ 23 dBm
510
mA
WCDMA B5 HSDPA CH4407 @ 22.9 dBm
600
mA
WCDMA B5 HSUPA CH4407 @ 22.9 dBm
600
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B2 CH900 @ 23 dBm
700
mA
LTE-FDD B4 CH2175 @ 22.8 dBm
650
mA
LTE-FDD B5 CH2525 @ 23.1 dBm
680
mA
LTE-FDD B7 CH3100 @ 24.2 dBm
895
mA
LTE-FDD B12 CH5095 @ 22.9 dBm
670
mA
