Quectel MC60 Series User Manual

GSM/GPRS/GNSS Module Series
MC60 Series Hardware Design
MC60_Series_Hardware_Design Confidential / Released 13 / 114
The module fully complies with the RoHS directive of the European Union.
2.2. Key Features
The following table describes the detailed features of MC60.
Table 1: Key Features (GMS/GPRS Part of MC60)
Features
Implementation
Power Supply
Single supply voltage: 3.3V~4.6V
Typical supply voltage: 4V
Power Saving
Typical power consumption in Sleep mode (GNSS is powered off):
1.2mA @DRX=5
0.8mA @DRX=9
Frequency Bands
 Quad-band: GSM850, EGSM900, DCS1800, PCS1900
 The module can search these frequency bands automatically.
 The frequency bands can be set by AT commands.
 Compliant to GSM Phase 2/2+
GSM Class
Small MS
Transmitting Power
 Class 4 (2W) at GSM850 and EGSM900
 Class 1 (1W) at DCS1800 and PCS1900
GPRS Connectivity
 GPRS multi-slot class 12 (default)
 GPRS multi-slot class 1~12 (configurable)
 GPRS mobile station class B
DATA GPRS
 GPRS data downlink transfer: max 85.6kbps
 GPRS data uplink transfer: max 85.6kbps
 Coding scheme: CS-1, CS-2, CS-3 and CS-4
 Support the protocol PAP (Password Authentication Protocol) usually
used for PPP connection
 Internet service protocols TCP/UDP, FTP, PPP, HTTP, NTP, PING, etc.
 Support Packet Broadcast Control Channel (PBCCH)
 Support Unstructured Supplementary Service Data (USSD)
Temperature Range
 Operation temperature range: -35°C ~ +75°C
1)
 Extended temperature range: -40°C ~ +85°C
2)
(U)SIM Card Interface
 Support (U)SIM: 1.8V, 3.0V
 Support Dual (U)SIM Single Standby
SMS
 Text and PDU mode
 SMS storage: (U)SIM card
Quectel
Confidential
