Raisecom ISCOM2600 (B) Series User Manual

Raisecom
ISCOM2600 (B) Series Product Description
2 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
13
7
USB, PWR, SYS, SNMP, MST, and STK LEDs
8
USB interface
Figure 2-2 shows the rear panel of the ISCOM2600-28X-AC.
Figure 2-2 Rear panel of the ISCOM2600-28X-AC
ISCOM2600-28X-DC
Figure 2-3 shows the front panel of the ISCOM2600-28X-DC.
Figure 2-3 Front panel of the ISCOM2600-28X-DC
1
Ground terminal
2
Power interface
3
Service interfaces (1–28) LEDs
4
Service downlink interfaces (1–24)
5
Service uplink interfaces (25–28)
6
SNMP interface and Console interface
7
USB, PWR, SYS, SNMP, MST, and STK LEDs
8
USB interface
Figure 2-4 shows the rear panel of the ISCOM2600-28X-DC.
Figure 2-4 Rear panel of the ISCOM2600-28X-DC
2.1.2 ISCOM2600-28G
ISCOM2600-28G-AC
Figure 2-5 shows the front panel of the ISCOM2600-28G-AC.
