Raisecom ISCOM2600 (B) Series User Manual

Raisecom
ISCOM2600 (B) Series Product Description
2 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
40
2.6.5 AC power cable
Introduction
The AC power cable transmits 220 VAC power to the power interface on the ISCOM2600
series switch, and supplies power for the whole device.
The AC power cables used by the ISCOM2600 series switch vary with countries or regions,
as lists in Table 2-19.
Table 2-19 AC power cables
Regional standard
Cable
Europe
POL-AC-European-3-pin/C13 connector-0.75mm
2
-1.5m/RoHS
America
POL-AC-American-3-pin/C13 connector-18AWG-1.5m/RoHS
Appearance
The AC power cable which meets European standard is composed of the European French
mode 3-pin plug and C13 connector, as shown in Figure 2-46.
Figure 2-46 European AC power cable
The AC power cable which meets American standard is composed of the American 3-pin plug
and C13 connector, as shown in Figure 2-47.
Figure 2-47 American AC power cable
Technical specifications
Table 2-20 lists technical specifications of the European AC power cable.
Table 2-20 Technical specifications of the European AC power cable
Parameter
Description
Name
POL-AC-European-3-pin/C13 connector-0.75mm
2
-1.5m/RoHS
Color
Outer
Black (PVC insulation layer)
