16 C-Series Display Reference Manual
Adjusting the display lighting
The display has two distinct color palettes, for day and night operation. You can also
manually adjust the backlight level.
Note: The display lighting is a local setting and will therefore only affect the individual
display on which you are working.
Day/night operation
To select the day/night mode of operation:
The display saves the current palette when the unit is powered off. If the palette was set
to NIGHT when it was last used, and you then power on in bright sunlight, it may be
difficult to see the screen. Reset the palette to DAY to return to normal daytime
lighting.
Backlight level
To adjust the backlight level when in day or night operation mode:
D6802-3
Toggle as required
OK
PALETTE
DAY NIGHT
D8517_1
Backlight Level
Change the level as required
OK
81221_4.book Page 16 Tuesday, February 28, 2006 5:24 PM
